The low cost, high performance, and small form factor of NanoStationM and NanoStationlocoM make them extremely versatile and economical to deploy.
Quick Specs
Figure 1 shows the appearance of LocoM2.
Table 1 shows the Quick Specs.
|
Product Code |
LocoM2 |
|
Power Supply (PoE) |
24V, 0.5A |
|
Max. Power Consumption 5.5W |
5.5W |
|
Memory |
32 MB SDRAM, 8 MB Flash |
|
Dimensions |
161 x 31 x 80 mm |
Product Details
Figure 2 shows the front panel of LocoM2.
Figure 3 shows the back panel of LocoM2.
Figure 4 shows the bottom panel of LocoM2.
LocoM2 provides these features:
- Versatile Mounting
- Improved Surge Protection
- Efficient Footprint
- Quick Installation
Compare to Similar Items
Table 2 shows the comparison of LocoM2.
|
Module |
LocoM2 |
|
|
Power Supply (PoE) |
24V, 0.5A |
24V, 0.5A |
|
Max. Power Consumption 5.5W |
5.5W |
5.5W |
|
Memory |
64 MB DDR2, 8 MB Flash |
32 MB SDRAM, 8 MB Flash |
|
Dimensions |
161 x 31 x 80 mm |
161 x 31 x 80 mm |
Get More Information
Do you have any question about the LocoM2?
Contact us now via Live Chat or [email protected].
LocoM2 Specification
LocoM2 specification |
|
|
Dimensions |
161 x 31 x 80 mm |
|
Power Supply (PoE) 24V, 0.5A |
24V, 0.5A |
|
Max. Power Consumption 5.5W |
5.5W |
|
Power Method |
Passive PoE (Pairs 4, 5+; 7, 8 Return) |
|
Operating Frequency |
2412-2462 MHz |
|
Gain |
8.5 dBi |
|
Networking Interface |
(1) 10/100 Ethernet Port |
|
Processor Specs |
Atheros MIPS 24Kc, 400 MHz |
|
Memory |
32 MB SDRAM, 8 MB Flash |
|
Frequency |
2.4 GHz |
|
Cross-pol Isolation |
20 dB Minimum |
|
Max. VSWR |
1.4:1 |
|
Beamwidth |
60° (H-pol) / 60° (V-pol) / 60° (Elevation) |
|
Polarization |
Dual Linear |
|
Enclosure |
Outdoor UV Stabilized Plastic |
|
Mounting |
Pole-Mount (Kit Included) |
|
Operating Temperature |
-30 to 75° C (-22 to 167° F) |
|
Operating Humidity |
5 to 95% Noncondensing |
|
Wireless Approvals |
FCC Part 15.247, IC RS210, CE |
|
RoHS Compliance |
Yes |
|
Shock & Vibration |
ETSI300-019-1.4 |
